ZTE MF286D Cat12 CPE Mesh Router with Gigabit Port Support Carrier Aggregation

It is designed to meet the needs of high-speed WLAN any time and any place. Based on LTE category 12, ZTE MF286D CPE could achieve download speed up to 1.3Gbps, which are the double speed of the predecessor of ZTE MF283 and mf293N and bring a fluid and enjoyable internet experience even when the internet connection is shared between users. Up to 64 users could connected with ZTE MF286D CPE and surf simultaneously.

This ZTE MF286D CPE router is in ready stock, it’s hot demand Modem.

If you need any zte antennas, please check our product list for antennas.

WIFI antenna booster External LTE Indoor Antenna sma Omni Directional for zte 4G 5G modem

ZTE MF286 LTE Router Technical Specifications

ZTE MF286 LTE Cat6 CPE Technical Specifications:

* LTE Cat6 wireless router/CPE (portable)

* Chipset: Qualcomm WTR3925 (28nm process) and Qualcomm MDM9230 (20nm process)

* Support LTE FDD/LTE TDD/UMTS/GSM networks

* Support 4G LTE Band 1/3/7/8/20 (700/900/1800/2100/2600MHz)

* Support 3G Band 900/2100MHz and 2G GSM 850/900/1800/1900MHz

* FDD-LTE download speed to 300mbps and upload speed to 50mbps

* TDD-LTE download speed to 220+mbps and upload speed to 10+mbps

* 3G DC-HSPA+ download speed to 42mbps and upload speed to 11.2mbps

* WiFi standard: 802.11 b/g/n/ac; 2.4 GHz 3 x 3 MIMO, peak speed to 450Mbps; 5 GHz, 2 x 2 MIMO, peak speed to 867 Mbps

* Support up to 64 wireless devices to access the internet simultaneously

* Support VoLTE Call in high quality

* Built-in Battery: 3000mAh, support a conference call for up to 4 hours or share a 4G network for up to 3 hours

* Interfaces: 4 * RJ 45(GE 1 * WAN/LAN + 3 * LAN) + 2 * RJ11 + 1 * USB

* WiFi range: covers more than 500 square meters

* USB interface to share pictures, files or videos by a USB Disk or a small hard disk through same WiFi network

* Special features: CSFB/VoLTE via RJ11, HD Voice, Web UI, IPV6, WPS

ZTE MF286D LTE router:

As the highest level among current 4G wireless router, ZTE MF286 LTE Router pairs the Qualcomm WTR3925 RF transceiver chipset based on the 28 nm process with the Qualcomm MDM9230 modem based on the 20 nm process. The new chipsets perform better and consume less power. In terms of a Wi-Fi network, it supports 802.11b/g/n/ac and 3 x 3 multiple-input multiple-output (MIMO) technology with three spatial streams for maximum performance. And the WiFi of ZTE MF286 operates on both 2.4GHz and 5GHz. The ZTE MF286 features are very similar to Huawei E5186 LTE Cat6 CPE.

MF286D CA&4MIMO Capacity:

DL UL DL 4X4 MIMO
CA_1C
CA_1A-3A CA_1A4-3A2，CA_1A2-3A4
CA_1A-7A 1A-7A CA_1A4-7A2，CA_1A2-7A4
CA_1A-8A CA_1A4-8A2
CA_1A-20A 1A4-20A2
CA_1A-28A CA_1A4-28A2
CA_1A-32A CA_1A4-32A2
CA_1A-38A
CA_1A-42A
CA_20A-32A
CA_20A-38A CA_20A2-38A4
CA_28A-42A
CA_38C
CA_3A-20A 3A-20A CA_3A4-20A2
CA_3A-28A CA_3A4-28A2
CA_3A-32A
CA_3A-38A CA_3A4-38A2，CA_3A2-38A4
CA_3A-3A CA_3A4-3A2
CA_3A-42A CA_3A2-42A4
CA_3A-7A 3A-7A CA_3A4-7A2，CA_3A2-7A4
CA_3A-8A CA_3A4-8A2
CA_3C 3C
CA_42A-42A
CA_7A-20A CA_7A4-20A2
CA_7A-28A CA_7A4-28A2
CA_7A-7A CA_7A4-7A2
CA_7A-8A CA_7A4-8A2
