Alcatel LinkHub HH41NH 4G CPE WIFI Router

Alcatel Linkhub HH41 is a new 4G LTE Cat4 home station with two RJ45 Ethernet ports, one Micro USB port, two external SMA antenna connectors, and one SIM card slot. Like the brother model LinkHub HH40, the WiFi of Alcatel Linkhub HH41 could cover around strong 250 meters on single-band 2.4GHz.

Different from the Alcatel Linkhub HH40, the Linkhub HH41 has one RJ11 port for a telephone. Based on Qualcomm MDM9207+QCA 9531 platform, Alcatel HH41 Linkhub could provide fast speed up to 150Mbps and upload speed to 50Mbps.

Alcatel HH41 WiFi Router could connect up to 32 WiFi devices and 2 LAN network devices. Thanks to the Alcatel WiFi Link App, users can easily manage and control your Linkhub straight from the smartphones. Linkhub HH41 is the best solution for small offices, frequency home movers and second houses.

Alcatel Linkhub HH41 Technical Specifications

* Network Frequency Bands:
EU Version:
-FDD-LTE Band 1, 3, 7, 8, 20, TDD-LTE Band 38
-UMTS B1, 3, 8
-GMS: 850/900/1800/1900 MHz

 APAC/MEA Version:
> FDD LTE B1,3,5, (26),7,8,20,28
> TDD LTE B38,40
> UMTS B1,5,8
> GSM 850/900/1800/1900MHz

LATAM Version:
– FDD LTE Band 2, 3, 4, 5, 7, 17/12, 20, 28 Compatible B13
– UMTS B1, 2, 4, 5, 8
– GSM 850/900/1800/1900MHz

* Platform/Chipset: Qualcomm MDM9207 + QCA 9531

* Data Speed: DL up to 150Mbps, UL up to 50Mbps

* Display: LED lights (Power, Signal, WiFi, LAN, Network)

* Memory: 128MB LPDDR2 SDRAM, 256MB NAND Flash

* Browser: IE, Safari, Firefox, Opera, Chrome

* Configuration: Web UI (Mobile and PC versions), APP (IOS 5.0 ~9.x and Android 4.2)

* Language: English, French, Italian, Spanish (for the generic version.)

* Other languages available: upon request.

* WLAN: Wi-Fi 802.11b/g/n, 2.4GHz, 2×2 MIMO

* Support Up to 32 WiFi users and 2 LAN network

* Interfaces of HH41NH:
– 1 x Micro SIM card slot (3FF)
– 2 x 100Mbps LAN (RJ45)
– 1 x RJ11 port for telephone
– 2 x External SMA LTE antenna connectors
– 1 x Micro USB for power supply
– 1 x WPS key
– 1 x Reset hole

HH41 Technical features:

* Firewall, port forwarding, DHCP server

* Supported OS: Windows10, 8/7, Vista, XP, Mac OS X(10.6.X-10.10.X-)

* Certifications: CE, RoHS, REACH, WEEE, Wi-Fi alliance

* Support up to 64 wireless devices to access the internet simultaneously

* Support VoLTE Call in high quality

* Built-in Battery: 3000mAh, support a conference call for up to 4 hours or share a 4G network for up to 3 hours

* Interfaces: 4 * RJ 45(GE 1 * WAN/LAN + 3 * LAN) + 2 * RJ11 + 1 * USB

* WiFi range: covers more than 500 square meters

* USB interface to share pictures, files or videos by a USB Disk or a small hard disk through same WiFi network

* Special features: CSFB/VoLTE via RJ11, HD Voice, Web UI, IPV6, WPS

The Alcatel LINK HUB HH41NH combines fast LTE download speeds with Wi-Fi coverage of up to 250 meters to blanket your home or office with high-speed service.

MAXIMIZED CONNECTIONS Connect up to 32 Wi-Fi devices and two LAN network devices at the same time, so you can browse the internet, stay updated on social media, and shop online using your own private Wi-Fi network.

MORE COVERAGE LTE support makes the Alcatel LINK HUB HH41 a perfect option for homes or businesses that may not have access to high-speed landline Internet or phone services.
