Powerful 4G router Huawei B525s-23a cat6 wireless router

Stock 4G router Huawei B525s-23a cat 6 LTE-Advanced Router

White/Black two colors

Access to LTE wireless networks
Access to Gigabit Ethernet networks
High-speed data access
Complies with wireless 802.11b/g/n standards with data rates up to 300 Mbit/s
Complies with wireless 802.11a/ac standards with data rates up to 1300 Mbit/s
SMS
Pv4 /IPv6 dual stack
Compatibility with RJ11 telephone ports; can be set to Voice over Internet Protocol
(VoIP) voice mode or Circuit Switch (CS) voice mode

Download Huawei b525s-23a 4g cpe router datasheet

Brand: Huawei

Networking products

Huawei wireless router

Top ZTE Pocket WIFI

5G Wifi Router

4G CPE Router

4G Mobile Hotspot

3G Modem Router

4G USB Modem

Mesh Router & Booster

PON & DSL

Antenna & Adapter

Main Brands

HTC

Alcatel

Asus

D-Link

Fiberhome

Franklin

Huawei

162

Inseego

Linksys

Netgear

Nokia

OEM

Oppo

Samsung

Sierra wireless

TCL

TP-Link

ZTE

Zyxel

Need consultation?

Share your idea, We’ll find solution for you within 24 hours

The HUAWEI B525s-23a LTE CPE (B525s-23a for short) is a wireless gateway that
integrates LTE and high-speed Ethernet uplink access, which provides users with flexible and
diversified data access and voice services.

Huawei B525 CPE is a powerful 4G LTE Ultra desktop router so that you will enjoy the fastest wireless internet in your home or office. With this application HiLink (available on Android and IOS), the B525 LTE CPE can be managed remotely using your smartphone.

Huawei B525s-23a Technical specifications:

Item	Description
Model	B525s-23a
Product Type	4G LTE cat6 wireless router
Working Frequency	LTE: B1/3/7/8/20/32/38
	FDD: 2100 MHz/1800 MHz/2600 MHz/ 900 MHz/800 MHz/1500 MHz/
	TDD: 2600 MHz Intra-band contiguous: B3+B3, B7+B7, B38+B38 Inter-band: B3+B7, B3+B20, B7+B20, B7+B8, B3+B8, B1+B20, B1+B8, B20+B32
	DC-HSPA+/HSPA+/ HSPA/UMTS:Band 1/8 2100 MHz /900 MHz
	EDGE/GPRS/GSM:Band 2/3/5/8 1900 MHz/1800 MHz/850 MHz/900 MHz
	Wlan 2.4GHz 2.402 GHz～2.472 GHz
	Wlan 5GHz 5.150GHz～5.350GHz & 5.470GHz～5.725GH
Technical Standard	Wan:LTE/DC-HSPA+/HSPA+/HSPA/UMTS/EDGE/GPRS/GSM Lan:IEEE 802.3/802.3u Wlan: IEEE 802.11a/b/g/n/ac
External Port	1x power adapter port 3xLAN port (RJ45) 1x LAN/WAN port (RJ45) One phone port (RJ11) Two external LTE antenna ports (SMA-J1.5) One micro-SIM card slot One USB 2.0 port (Supports a maximum of 500mA current)
Antennas	Built-in LTE/UMTS/GSM primary antenna Built-in LTE/UMTS secondary antenna Built-in WLAN 2.4G antenna Built-in WLAN 5G antenna
Button	One Power ON or OFF switch One WPS button One Reset button
