New 4G EE&BT router Alcatel Linkhub HH70 LTE Cat7 Home Station

New 4G EE&BT router Alcatel Linkhub HH70 LTE Cat7 Home Station

Alcatel LTE WIFI router Alcatel Linkhub HH70 LTE cat 7 Home station

Alcatel Linkhub HH70 LTE router main features:

  • 4G cat 7 WIFI router
  • WLAN 2.4GHz and 5GHz support WIFI AC(1300Mbps)
  • LTE download speed up to 300Mbps
  • Support Web UI (Mobile and PC versions)
  • With 4FF SIM card slot
  • Antenna: External antenna connectors (2x)



Version EE and BT(HH70VB& HH70BT)

Color: White and Black

Networking products

Main Brands

Need consultation?

Share your idea, We’ll find solution for you within 24 hours

Wholesale Alcatel Linkhub HH70 4G LTE Cat7 Home Station

with Ethernet port and sim card

Alcatel Linkhub HH70 is a new LTE Cat7 home station which has two Ethernet ports(one for LAN and the other for LAN/WAN), one USB port and one RJ11 telephone port. With the support of LTE Cat7, Alcatel Linkhub HH70 could achieve download speed up to 300Mbps and upload speed to 100Mbps. It can provide strong WiFi coverage of 250 meters. Like its predecessor Alcatel Linkhub HH40, it also has two connectors for a 3G/4G external antenna.

Alcatel Linkhub HH70 Cat7 router could support up to 64 WiFi devices simultaneously on dual-band WiFi(2.4GHz & 5GHz).

Thanks to Alcatel WiFi Link App, users can easily manage and control the Linkhub straight from the smartphones.

The LinkHub HH70 is the best solution for small offices, frequent home movers and second houses.

Alcatel Linkhub hh70 Technical Specifications:

Item Description
Model HH70( HH70VB& HH70TB)
Product Type 4G WIFI ROUTER MODEM
Platform/chipset Qualcomm MDM9240-1
Memory  4GB NAND Flash + 2GB LPDDR2
LTE category LTE Cat7
Network Wlan:  Wi-Fi 802.11 a/b/g/n/ac, dual-band(2.4GHz & 5GHz), 2 x 2 MIMO
4G LTE Band: FDD LTE B1/3/7/8/20 & TDD B38/B40
3G UMTS B1/3/8
2G GSM: 850/900/1800/1900MHz
LED Peak speed LTE download speed up to 300Mbps, upload speed up to 100Mbps
3G speed DC-HSPA+DL (DOWNLOAD) up to 43.2Mbps
DC-HSPA+UL (UPLOAD) up to 5.76Mbps
Users Maximum up to 64 WiFi users
Display LED lights (Power, Signal, WiFi, TEL, Network)
Interface
  • 4FF SIM card slot
  • 2x 1000Mbps RJ45 port (WAN/LAN)
  •  1x RJ11 port
  • USB 2.0A for external disk connection and printer
  • AC/DC charger
  • External antenna connectors (2x)
  • 1x Power key
  •  1x WPS key
  • 1x Reset hole

-Browser: IE, Safari, Firefox, Opera, Chrome

– Languages: English, French, Italian, Spanish (for the generic version.)

-Configuration: Web UI (Mobile and PC versions) APP (IOS 5.0 ~9.x and Android 4.2)

-OS: Windows10, 8/7, vista, XP, Mac OS X(10.6.X-10.10.X-)

-Certifications: CE, RoHS, REACH, WEEE, WiFi alliance

Alcatel Linkhub hh70 product image:

Alcatel HH70 EE router
Alcatel HH70 EE router
Alcatel LinkHub HH70 interface
Alcatel LinkHub HH70 interface
Alcatel LinkHub HH70
Alcatel LinkHub HH70
Alcatel HH70 Cat7 LTE Router BT
Alcatel HH70 Cat7 LTE Router BT
Alcatel LinkHub HH70 BT& EE
Alcatel LinkHub HH70 BT& EE
Alcatel HH70 test
Alcatel HH70 test
Alcatel HH70 LTE router power on
Alcatel HH70 LTE router power on
